Open PC Frame 2 case Rev 1

Revision of the Open PC frame II. Less filament and much cleaner. The blue parts in the frame pictures are the revised ones.

Mobo sits on 5.5 mm tall printed spacers (glue on after putting in the heat inserts).

Printed in carbon fiber PETG, 15% infill, 4 perimeters, 5 bottom and 7 top layers.

Do not use PLA as it will get soft at 60C.

Best to stick with flexible tubing. Although the design uses the components for extra rigidity, it is more flexible then a metal case. Make the connection tube between the card and the processor block long enough so you can easily take out the card to work on the MB.

Made for Rog Maximus XII Extreme (ATX extended) but other MBs will fit of course. Power supply: EVGA SuperNOVA 220-G3-1000-X1,1000 G3, 80 Plus Gold 1000W Radiators: EKWB EK-CoolStream SE 360 Radiator, Slim Triple, Black Reservoir/pump EK-Quantum Kinetic FLT 240 D5 PWM D-RGB EKWB EK-Quantum Torque STC-10/13 Compression Fitting for Soft Tubing EKWB EK-AF Classic G1/4" 90° and 45°Angled Fittings. 20 and 30mm extender fittings. NOYITO 16mm Chassis Switch Metal Button Switch.

You need some assorted 6-32 screws to put the frame together, for power supply and reservoir.

6-32, 1 3/4 in screws for the fans and radiators.

M3 screws to put things together.

Use cyanoacrylamide and kicker on the threads if M3 screws don't hold. M3 heat inserts and M3 screws for the Mobo.

Please realize that I only share designs I make for myself. They are shared all under non-commercial share alike license. This is meant for makers and requires some careful consideration and tools. Importantly, this is a experimental design and not a commercial product. If someone sold this to you (they shouldn't) do not complain to me or ask for changes, I am not involved. Please send feedback and concerns.
