Quickfix-JB4 Junction Box Mounting Plate

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
STL
  • 2 Likes
  • 42 Downloads
  • 0 Makes
  • 1 Comments
  • 683 Views

Author:Andrew Leigh

Published

Download on Printables

Description

A Quickfix junction box for Wago terminals is an excellent junction box, but provides no bracket. This design allows the junction box to be mounted to a wall or beam by screwing the mounting bracket then pushing the junction box into the bracket.

I suggest printing it in ASA or PETG. The one I printed was in Black Sunlu PETG.

Tags

mountingbracketjunctionbox
