10" Rack mount for 3x Raspberry Pi (3, 4 and 5) + 3x 2.5" drives (SSD/HDD)

This bracket is made for 10" racks. They have the standard dimensions of 1U (44.5mm) in height and 250mm in width. With these dimensions the mount can be printed on a print bed with the dimensions of 220mm x 220mm. The mount is designed to hold the units firmly in place without loosening. The use of screws to hold the units in place is necessary. If there is a wish to provide further files for other devices, please contact me by message.

You can print covers for RPI3, 4 and 5 or use a blank one, if you want. The covers can be attached from the inside and fit nicely, when the Pis are mounted. I used Arial Black as font, in case you want them to label yourself.

You can use the attached Drive Dummy and blank Pi Cover to hide the slots, if you don't use them. Print the parts as they're oriented.

Use supports for the cover models.
