SUBSTR system 10mm Ball-Hinge-Ball (BHB) joint

Model details

Platform
Printables
Price
Free
License
CC-BY-SA
Print, modify and sell with credit; share remixes under the same license.
Formats
3MF
  • 25 Likes
  • 449 Downloads
  • 0 Makes
  • 0 Comments
  • 1 319 Views

Author:Kexana

Published

Download on Printables

Description

This is a 10mm Ball-Hinge-Ball joint for use in the Substratum figure building system I will be utilise in my projects.

It should be simple enough to print but the dowel might be a bit hade to insert at first, this is in order for the joint to be tight.

The ball ends of the joint are 6mm in diameter.

You should print: 1x HingeJointBigDowel 2x BallHingeJoint10x6mmMain

Print Settings

Printer Brand:

Prusa

Printer: Prusa Clone

**Rafts:**

No

Supports: Yes

Category: Construction Toys
