Stepper motor(28BYJ-48) and Driver board(ULN2003) Mounting Bracket

Model details

Platform
Thingiverse
Price
Free
License
CC-BY
Print, modify and use commercially — credit the author.
  • 546 Likes
  • 3 190 Downloads
  • 2 Makes
  • 585 Collected
  • 2 Comments
  • 9 935 Views

Author:Tokyo_Bird

Published

Download on Thingiverse

Description

【Stepper motor(28BYJ-48) and Driver board(ULN2003) Mounting Bracket】 ステッピングモーター(28BYJ-48)とドライバーボード(ULN2003)を固定するためのシンプルなブラケットです。 ケーブルを収納しステッピングモーターとドライバーボードを固定することにより、動作テストやテスト環境で便利に使えます。

【Google Translation】 A simple bracket for fixing the stepping motor (28BYJ-48) and driver board (ULN2003). By storing the cable and fixing the stepping motor and driver board, it can be conveniently used in operation tests and test environments.

【Posted blog】 <a href="https://burariweb.info/electronic-work/stepping-motor-bracket.html" target="_blank" rel="noopener">小型ステッピングモーター(28BYJ-48)とドライバボード(ULN2003)をマウントできるブラケットを作ってみました。テスト環境で便利に使えます！</a>

【Items used】 ・<a href="https://www.amazon.co.jp/gp/product/B07LBRNZB6?ie=UTF8&psc=1&linkCode=sl1&tag=gekiyasuco089-22&linkId=20683e401a5bf485079046bbe3d7f000&language=ja_JP&ref_=as_li_ss_tl" target="_blank" rel="noopener">Stepper Motor(28BYJ-48)</a>

Tags

28byj-4828byj48bracketmounting bracketstepperstepper motorstepper motor mountuln2003uln2003 28byj-48
