80mm PCI Exhaust bracket

Model details

Platform
Thingiverse
Price
Free
License
CC-BY
Print, modify and use commercially — credit the author.
  • 51 Likes
  • 585 Downloads
  • 0 Makes
  • 60 Collected
  • 7 Comments
  • 3 218 Views

Author:HerpertDerpington

Published

Download on Thingiverse

Description

Modified version of drbrandt's PCI exhaust fan that fits an 80mm fan.

I have a 4U server case that has insufficient exhaust for the amount of air it takes in. I figured out that the 2x 80mm fans it had were only removing air from the CPU area of the case. I needed to pull air across a SATA controller and eventually an HBA.

I have added a second version where the fan is mounted facing down.

ABS is recommended if it is mounted close to expansion cards.
