Antibodies interacting with antigen

Molecular surface representation of two antibodies interacting with the same antigen. PDB entries 1fdl and 1yqv were matched on the Y chain and then antibody structures from PDB entries 1igt and 1igy were matched with the Fab fragments from PDB entries 1fdl and 1yqv. Immunoglobulins heavy chains were printed in red and green, while light chains are in yellow. The antigen (Hen Egg White Lysozyme from 1fdl ) was printed in white. Each component is provided as a separate stl file. A .py session file usable in Chimera is also provided to help the assembly. The model was created to help to teach Biochemistry and Molecular Biology at the undergrad level. Great for teaching structural biology and for visualizing molecular movement. Details on the structure and implications are available on PDB101: https://pdb101.rcsb.org/motm/21.

Printer Technology/Material Polylactic Acid (PLA) Printer Make/Model Creality Ender 5 Pro Print Units mm Scale At Given Print Units 100x Pre- and Postprocessing Instructions Printed at 0.2 resolution with 2 wall lines and 5% infill. Extensive supports are required but were rather easy to remove. Models are really fragile in the hinge region broke during handling, but were easy to glue back together.
