T-Track rail easy to print - no support

This is a t-track with official measurement, except the profil is 45° instead of 90° for an easy print without support, otherwise it is a mess to print and to get correct clearance.

Size is 280mm , but ask for other size if you want to adapt to your 3D printer.

Conform to dimension of what you can buy on the net, and especially to https://fr.aliexpress.com/item/1005002675903572.html?spm=a2g0o.cart.0.0.17cc378dUKSlD0&mp=1&gatewayAdapt=glo2fra

included:

T-track 280mm : ---------------------

T-track rail 280 mm, holes are 5mm and 6mm. [0.76€ 43gr, 13,41m 20% 4h50mn ] 20% 4 wall lines T-track miter 280mm : print with no border, but support. [ 0,53€, 30g 9,33m 3h21mn] 20% 4 wall lines

T-track 220mm -------------------- T-track rail 220 mm T-track miter 220mm

T-Track 300mm -------------------- T-track rail 300 mm [0,82€, 46g, 14,42m, 5h17mn] T-track miter 300mm [0,58€, 32g, 10,19m, 3h44mn]

16/01/2022: Upon request add more screw holes on each T Track in order to remove the flexing due to plastic (one hole every length T-track/4) : deliver new STL: T-trail_Rail_280mm_v2.stl T-trail_Rail_220mm_v2.stl T-trail_Rail_300mm_v2.stl

Common ------------ T-track TPU spacer to reduce clearance (not needed) [ 0,01€, 1g, 0,16m, 4mn] 20% 4 wall ines Small T-track nuts (30mm) with hole screw of 8mm [ 0,07€ 4g, 1,16m, 0h31mn] 20% 4 wall lines
