Rectangle Faucet Aerator Adapter

I got tired of using a rectangle faucet without an aerator. but I couldn't find an aerator for my faucet because it has a rectangular profile. Therefore, I decided to make an adapter from a rectangular profile to a round one, to which standard (or custom) round aerators with a 24 mm metric thread can be screwed. The outer profile dimension of my faucet is 28.2 x 8.9 mm, the length of the straight section to the bend of the pipe is approximately 16 mm.

The thread depth of adapter is 4mm and there is also a 2mm recess for installing a rubber gasket. The adapter is installed with an adhesive connection, I used rubber glue, but any glue that is insoluble in water and can withstand the temperature of the water you use will work.

If your faucet has other size and you want to print an adapter for its size, write a comment, see if I can help you.

As a bonus, I add the models of aerators that I tested on this adapter and at least they work and pass water without splashing on you.
