Thrustmaster Steering Wheel 'Suicide' Spinner Knob Quick Release

Thrustmaster Steering Wheel 'Suicide' Spinner Knob Quick Release

I remixed this because I wanted a tool-less knob that I could pop on and off easy, and I wanted it to spin a little more freely with bearings, so...

Fits my Thrustmaster Force Feedback perfectly, should fit T300, etc... (props to philcotigo for that :)

Needs a minute of fiddling to get it on and off at first, but once you get the feel for it, it is super easy.

I left the screw holes in the hinge side just in case, but they are not needed (that was the main point of the remix :). The spacer also isn't absolutely necessary, just depends on your configuration of washer(s)/nut(s).

NOTE: As with the original "Thrustmaster T300 Wheel Knob Clamps (remixed FULspeed) by philcotigo" the knob is on the outside of the steering wheel, THERE IS ONLY ONE WAY OF MOUNTING THE CLAMP with this design.

Parts list: 2x standard 22x8x7 bearings 1x 5/16 x 3in bolt 1x lockwasher 1x wingnut

Remixed from: 'Thrustmaster T300 Wheel Knob Clamps (remixed FULspeed)' by philcotigo (https://www.thingiverse.com/thing:4824578) and 'Steering wheel knob' by FULspeed (https://www.thingiverse.com/thing:1511824) and used dadamgi's idea of a round ball Thanks!

I printed this on an Epax resin printer, my filament printer is down at the moment :( so I can't really give advice on supports or other printer settings, sorry

Let me know if you have any questions, please post pictures and send a like if you print this, thanks :)
