Arrow Fletching Jig Portable v.3 (Best w/ Resin)

Model details

Platform
Thingiverse
Price
Free
License
CC-BY-NC-ND
Non-commercial use only, with credit and no modified versions.
  • 12 Likes
  • 324 Downloads
  • 0 Makes
  • 15 Collected
  • 4 Comments
  • 2 713 Views

Author:emir_ismail

Published

Download on Thingiverse

Description

Please rescale to 0.01 Best print with resin. But I think its ok for FDM

PORTABLE FLETCHING JIG

For 5mm Arrow diameter with 1.75in Vanes And 8mm Arrow diameter with 2.25in Vanes

Upper Arm and Nock base can be swappable

Need : 5x 12mm M3 bolt 3x 15mm M3 bolt 8x M3 nut
