Flying bear ghost 5 lightweight carriage for orbiter v2 and volcano hotend

Update v2 ( Carriage version for Volcano Hotned )

Files: - Red-Mad-Goose-v2-volcano-carriage.stl - RMG-v2-volcano-fun-duct-1-left.stl - RMG-v2-volcano-fun-duct-2-front.stl

Updates: - The carriage has been slightly optimized for installing the Volcano Hotned.

Notes: The carriage file itself and 2 fun ducts for installation have been added. I tested the carriage with one cooling snail and one fun duct, as well as with two snails connected in parallel and installed in one package (2 fun ducts). In the second case, when two snails are installed for PETG plastic, you cannot turn on the airflow above 70-80%, otherwise the adhesion of the layers decreases, apparently because the plastic from the nozzle cools too quickly. In any case, it's up to you to decide.

----------------

Update v1 ( New carriage version added Red-Mad-Goose-v1-e3dv6.stl )

- Converted the linear bearings from PETG stubs to PTFE tube bores, which greatly improves sliding and reduces backlash - Moved the chain attachment point to the right to improve stability at high accelerations (>5k) - Added a mount for the adxl345 accelerometer - Added mount for BLTouch - Added a hole for cable entry - Added a support that clearly secures the bottom of the heatsink to reduce hotend wobble at high accelerations (>5k) - The carriage now has a “Red Mad Goose” name :)

----------------

Lightweight cage carriage for flying bear ghost 5 with orbiter v2 - Monocoque design reduces parasitic vibrations - Does not reduce the working area in X and Y, and increases in Z by 6mm. - Maximizes the use of stock carriage parts - Allows you to install e3dv6 hotend (x-carriage-v1.stl) or stock fb5 honend (x-carriage-stock-fb5-hotend-v1.stl). - Allows you to reduce the weight by more than 100 grams compared to the stock one - Optimal X strap mounting location - 180 degree inverted 5015 snail does not suck hot air from the table and cools the carriage optical sensor. - Quieter travel - Compatible with cable chain https://www.thingiverse.com/thing:3715002

After installing this cartridge the resonance amplitudes decreased by 3 times. I raised cruising print speeds to 160mm/sec, accelerations to 4000. For the test I printed at 200/7000, I didn't notice any problems, but I don't put such speed in everyday use on the bear yet
