Inspur LSI 9300-8i HBA Fan Shroud

Model details

Platform
Thingiverse
Price
Free
License
CC-BY-NC-SA
Non-commercial use only, with credit; share remixes under the same license.
  • 11 Likes
  • 336 Downloads
  • 0 Makes
  • 5 Collected
  • 5 Comments
  • 2 549 Views

Author:kevintateprojects

Published

Download on Thingiverse

Description

I bought a used [Inspur LSI 9300-8i HBA](https://www.ebay.com/itm/196952431545?mkcid=16&mkevt=1&mkrid=711-127632-2357-0&ssspo=JZcP7KayTEK&sssrc=2047675&ssuid=&widget_ver=artemis&media=COPY) from eBay for use in my old tower and I found that it would get too hot without active cooling. I wasn't a fan of the other shrouds I found as they clipped to the heatsink. So I designed this one for use with a [Noctua NF-A4x20 fan](https://www.amazon.com/Noctua-NF-A4x20-PWM-Premium-Quality-Quiet/dp/B071W93333/ref=sr_1_1_pp?sr=8-1). It clips onto the back of the circuit board rather than hooking under the heatsink.

I've included the `.stl` as well as the FreeCAD `FCStd` file in case anyone wants to modify it.

**2025-09-15 Edit:** Added 10mm `.stl` and `FCStd` files at request of Neccros.
