Soviet project 123K torpedo boat

Full, RC ready, free model. Quite complicated and requires some skill to make it look like in the pictures. The body has to be reinforced with fiberglass at least inside and it is highly recommended to fiberglass the outer side of the hull for the sake of the smooth solid surface. All but the resin parts is printed on an ENDER3. Powered by two 2845 motors and 3S battery.

Assembly guide:

Hull 1) Put together parts BOW, B1, B2. Fiberglass inside. 2) Put together parts B3 through B8-STERN. Fiberglass inside. 3) Put together 1) and 2), glue TRANSOM onto the STERN. Fiberglass the seam between B2 and B3. 4) Postprocess the hull however you like. 5) Install WAVEPLATE V2 and TRANSOM SUPPORT A and B as in the pictures. Glue 4mm tubes into the holes the shafts would go through.

Cover 1) Glue DECKHOUSE_TOP to the DECKHOUSE 2) Glue REAR_COVER to the 1) 3) Glue VENTS to the DECKHOUSE

Torpedo tubes 1) TTL states for left torpedo tube, TTR for right. 2) Connect parts B through E toghether using the part SPACER 3) Glue part A to the part C 4) Install both torpedo tubes on the marked spots on the hull

Motors and servos 1) 2 SG90 servos are installed in the brackets inside the hull 2) MOTOR MOUNTS are glued inside the hull on the B3 part (mirror one). 3) Glue pieces of 4mm tube in the holes of part STERN 4) Make rudders using parts RUDDER, SERVO_HORN and M3 45 mm long screw as an axis.

Resin parts Honestly have no idea how to make them. I ordered the prints. Use photos for reference where to put them

Rubrails and hooks See photos. RUBRAIL_L goes to the left side, RUBRAIL RB abd RF to the right side. HOOK_REAR and HOOK_FRONT are same for both sides.
