Youtube demo video. Due to copyright concerns the audio is muted when the Dalek sound bytes are playing. Sorry. https://youtu.be/Ek8lwxzZ4EE

Youtube build video. Due to copyright concerns the audio is muted when the Dalek sound bytes are playing. https://youtu.be/JBPH7Tg9V7I

Edited 4/30/2026 to add Schematic.png and Dalek_EDA_Picaxe.zip which contains the EasyEdaPro schematic and board files and the Picaxe program file.

This is my 1/10 scale Dalek model that plays sound clips and has the arm, gun, and head animated. When the button on the front of the model is pressed it plays a sound clip and does the movement. The Dalek is controlled by a Picaxe 14M2 micro-controller. The Picaxe sends commands to a DV-SV17F sound module to play the sound files. It also turns the motor that does the animation on and off through a mosfet. It is powered by 3 AA batteries. The model could be built as a static model if you don't want to build the electronics.

I have included a zip file with the files for making the PCB and the program for the Picaxe 14M2. The schematic and circuit board were created with EasyEDA Pro which is free. The design file is included if you want to change it. The Gerber and drill files to make the PCB are in the zip file. I made my board using isolation routing on a 3018 CNC. You could use the Gerbers to order boards from PCBWAY or some other board manufacturer but I haven't tried that so I can't guarantee they will work.

The model was designed in Fusion 360. The dimensions are for the Shawcraft movie Daleks and came from the ProjectDalek group. You have to join the group to get access to the files.

The 3mf file is a Bambu Studio file.

power switch 19mm between screw hole centers https://www.amazon.com/dp/B008DFYHV2

push button switch 6mm X 6mm tactile switch measures 7mm from bottom of switch body to top of push button

3mm brass tubing

funky foam

screws 3mm Hex Socket Button Head Cap of various lengths https://www.amazon.com/dp/B08LVT7Y8R

screws 2mm X 6mm

leds red 3mm and red 1206 surface mount

gear motor 30 RPM 6V https://www.amazon.com/dp/B09W15J92J

AAA battery terminals https://www.amazon.com/dp/B0B1ZJ8PNH

28 MM speaker https://www.amazon.com/dp/B0C49RZ9WJ
