ESP12F RELAY 2X DIN-Rail-Housing

Model details

Platform
Thingiverse
Price
Free
License
CC-BY-NC-SA
Non-commercial use only, with credit; share remixes under the same license.
  • 1 Likes
  • 39 Downloads
  • 0 Makes
  • 0 Collected
  • 0 Comments
  • 366 Views

Author:9-R

Published

Download on Thingiverse

Description

# DIN-Rail-Housing for ESP12F RELAY 2X

This is a housing for the popular ESP12F Relay 2x.

It is intended for attachment to DIN-Rails but since the rail-clips are printed separately it can be used stand alone as well.

## Additional parts

| part | quantity | |:-------------------------|------------:| | M3x5 cheese head | 2 | | M3x10 cheese head | 2 | | M3x5 counter sunk | 4 | | M3 inserts OD4.5 | 4 | | zip tie | 1 |

Notes: * zip tie is only necessary if an additional gpio-cable will be used * Insert-OD can easily be adjusted to person preference in the FCStd dimensions table

## Recommended Print Setting

* 3 layer shell * 13% infill should suffice * support: not neccessary

### Orientation

| part | orientation | |---------- |-------------------| | base | flat side down | | lid | upside down | | clamps | sideways |

## Recognition

A sightly modified version of [mdkendalls design](https://www.thingiverse.com/thing:2613804) was used for the DIN-rail clamp.
