TV rear mount for Lenovo Tiny PCs, VESA 200x200 Corner Mount

Simple corner mounting brackets for TV or monitor VESA 200 x 200 mm mount.

You can use M6 x 15mm or M6 x 18mm screws to fasten to your TV.

The brackets will work for any Lenovo Tiny PCs having dimensions of: 179 x 183 x 37 mm

I used it for a M75q-1 but it may work for other models such as: M720q, M920q, M920x, P330, M75q, M75q Gen 2, M70q, M80q, M90q, P340, M70q Gen 2, M90q Gen 2, P350, M80q Gen 3, M90q Gen 3, P360, etc.

This mount uses less plastic than most designs I found and leaves the device uncovered, so it gets better airflow than those bulky designs that box everything in.

Printed using PLA and used tree type support material for the overhangs. Turned out great.
