Magnetic 3D Scanner Turntable Helping Hands Adapter for SMMT | "Dritte Hand" Adapter für Magnetischen 3D Scanner Drehteller für SMMT

Model details

Platform
Thingiverse
Price
Free
License
CC-BY-NC-SA
Non-commercial use only, with credit; share remixes under the same license.
  • 55 Likes
  • 286 Downloads
  • 0 Makes
  • 9 Collected
  • 0 Comments
  • 3 799 Views

This model on other platforms

Author:Alvomane

Published

Description

####EN: This is a magnetic Helping Hands adapter for my [SMMT](https://makerworld.com/de/collections/4545861-smmt-small-modular-marker-tower) -compatible [30 cm scan plate](https://www.thingiverse.com/thing:7133655). Simply screw the movable Helping Hands arms into the adapter, then glue the magnets (10x2) into the recesses and cover them flush with 10/6 mm scan markers. The modular [SMMT marker Towers](https://makerworld.com/de/collections/4545861-smmt-small-modular-marker-tower) from [Paw85](https://makerworld.com/en/@Paw85) can be positioned on the turntable as usual with my magnetic adapter base (SMMT-Magnet-Base.stl), but also on the Helping Hands adapter. 10x2 magnets are also glued into the adapter base. Please note the polarisation before gluing.

**------------ I would be very happy if you have as much fun with the things as I do. ------------ -------------- [If you like, buy Me a Coffee at ko-fi.com](https://ko-fi.com/alvomane) :-). Thank you very much! --------------**

####DE: Das ist ein magnetischer "Dritte Hand"-Adapter für meinen [SMMT](https://makerworld.com/de/collections/4545861-smmt-small-modular-marker-tower) kompatiblen [30cm Scanteller](https://www.thingiverse.com/thing:7133655). In den Adapter werden einfach die beweglichen "Dritte Hand"-Arme eingeschraubt, dann in die Aussparrungen die Magnete (10x2) eingeklebt und bündig mit 10/6mm Scanmarkern überklebt. Die modularen [SMMT Markertürme](https://makerworld.com/de/collections/4545861-smmt-small-modular-marker-tower) von [Paw85](https://makerworld.com/en/@Paw85) können mit meinem magentischen Adapterfuß (SMMT-Magnet-Base.stl) wie gehabt auf dem Drehteller aber auch auf dem "Dritte Hand"-Adapter positioniert werden. In den Adapterfuß werden gleichfalls 10x2 Magnete eingeklebt. Beachtet vor dem Verkleben bitte die Polarisation.
