Asrock AMD BC-250 Steam Machine

Here is my version of the BC-250 case. It is designed for the BC-250 motherboard and Flex ATX power supply. The case was created based on the case from @Arthrimus. The power supply compartment has been modified, it is slightly larger (42.2x83.8 mm) (the walls are thinner to keep the same case size as the original) and there are holes at the bottom to vent air from the power supply. The front panel is designed for a round button. I am also adding a bracket for two 120mm fans made by @isaacalvex.

<p>• Asrock AMD BC-250: <a href="https://pl.aliexpress.com/item/1005008976362329.html?spm=a2g0o.order_list.order_list_main.29.1fd81c24pkit6f&gatewayAdapt=glo2"> Aliexpress</a>.</p>

<p>• Power supply METALFISH FLEX 500W:<a href="https://pl.aliexpress.com/item/1005009609601844.html?spm=a2g0o.order_list.order_list_main.11.1fd81c24pkit6f&gatewayAdapt=glo2"> Aliexpress</a>.</p>

<p>• Switch (16mm, latching, 12V):<a href="https://pl.aliexpress.com/item/1005007067111695.html?spm=a2g0o.order_list.order_list_main.17.1e5b1c24itGmsp&gatewayAdapt=glo2"> Aliexpress</a>.</p>

<p>• Threaded inserts M3x3.5x4.6x6 (12 pcs):<a href="https://pl.aliexpress.com/item/1005005920120561.html?spm=a2g0o.order_list.order_list_main.23.1fd81c24pkit6f&gatewayAdapt=glo2"> Aliexpress</a>.</p>

<p>• Screws M3x6mm (12 pcs):<a href="https://pl.aliexpress.com/item/1005008082257314.html?spm=a2g0o.order_list.order_list_main.5.1fd81c24pkit6f&gatewayAdapt=glo2"> Aliexpress</a>.</p>

<p>• Screws M2x6mm (4 pcs):<a href="https://pl.aliexpress.com/item/1005008082257314.html?spm=a2g0o.order_list.order_list_main.4.1fd81c24pkit6f&gatewayAdapt=glo2"> Aliexpress</a>.</p>

<p>• Hub USB Anker 3.0:<a href="https://www.amazon.com/dp/B07L32B9C2?ref=cm_sw_r_cp_ud_dp_Z299BNBEQZFWGNYSKSJY& ref_=cm_sw_r_cp_ud_dp_Z299BNBEQZFWGNYSKSJY&social_share=cm_sw_r_cp_ud_dp_Z299BNBEQZFWGNYSKSJY&th=1"> Amazon</a>.</p>

<p>• USB 90 degrees 4 pcs (3 pcs on the front panel for the USB HUB and 1 pc on the back for connecting the cable from the USB HUB):<a href="https://www.amazon.com/dp/B0BVJXN99B?ref=cm_sw_r_cp_ud_dp_WV1GCNRN09R1QBDBQ7GQ& ref_=cm_sw_r_cp_ud_dp_WV1GCNRN09R1QBDBQ7GQ&social_share=cm_sw_r_cp_ud_dp_WV1GCNRN09R1QBDBQ7GQ&th=1"> Amazon</a>.</p>

<p>• Fan Arctic P12 Pro PWM (if you are using 2 fans, buy 1 PST because it has a splitter):<a href="https://www.amazon.com/ARCTIC-P12-PWM-PST-Connessione/dp/B07GJGF56L/ref=sr_1_3?crid=1AEJ37S06Z2WJ&dib=eyJ2IjoiMSJ9.hMjKweZLdI0KFP-x7rRcpac9-Q-jQ1qkqKDHd4YJT6nG_4j0OduT8D3syYEA64f5rwo33oATy3S1H_ew27TIx12sKj-A_qgrcIjSxYmhd8yXMTYGvmkODoPPl4w9UBnDv0SIKxLznh_PWro37rADaj-TMWW654o9kHCWciGNV2JXKGGHHnHE5-4FMGVEMAEZWihIGbQ_OcZiJjjGXblYDhDXSJBtF0gWF3EfoZ6XJvU.vHnQ7_DUQG-_Sk708voUxVgwX3-JxKOgU-OVzfLlfWE&dib_tag=se&keywords=Arctic%2BP12%2BPro&qid=1769099919&sprefix=arctic%2Bp12%2Bpro%2Caps%2C496&sr=8-3&th=1"> Amazon</a>.</p>
