Variable power supply enclosure SK120, ZK-4KX (regular 4mm banana plugs and smaller)
Variable power supply enclosure SK120, ZK-4KX (regular 4mm banana plugs and smaller) — Image 2 of 2
3D model · Thingiverse

Variable power supply enclosure SK120, ZK-4KX (regular 4mm banana plugs and smaller)

Model details

Platform
Thingiverse
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
  • 5 Likes
  • 101 Downloads
  • 0 Makes
  • 3 Collected
  • 0 Comments
  • 388 Views

Author:GunterG

Published

Download on Thingiverse

Description

I refined the main housing of that very nice original project (https://www.thingiverse.com/thing:7099981)

the differences just are: * widened banana-sockets (to 6mm) * the sockets for 4mm plugs come normally with a 10mm shield and so I did a slight/.5mm imprint * the through-holes are a bit stronger for daily use * the housing also got 4 rubber feet

the rest was just perfect for the original build :) / you will find the back-lid there

variant: * only 45mm depth (*-short) / ZK-4kX * smaller holes, easier to print, a bit more robust

Tags

power supplypower supply coversk120xzk-4kx
