Furniture Drilling Jig STL Models for 3D Printing

This collection gathers STL files for furniture drilling jigs, hinge mounts, marking templates, and pocket-hole guides. You can use them to print helpers that speed up cabinet and shelf assembly on a 3D printer. Compare several models to find the geometry that matches your tools and board thickness. Polyzon does not confirm whether models are free, their price, license, official status, affiliation, safety or fitness. Check the current terms at the source.

Esta colección está escrita en inglés, pero la búsqueda funciona en cualquier idioma.

Una colección de Polyzon · 48 modelos de 6 plataformas

Cómo se elabora esta colección

Polyzon reúne esta colección a partir de los resultados de búsqueda de las plataformas conectadas. Se eliminan los duplicados y los modelos sin vista previa, las coincidencias débiles van al final y el resto mantiene el orden de la búsqueda. Los modelos pertenecen a sus autores: consulta las condiciones en la página de cada modelo.

Criterios de selección: el equipo editorial de Polyzon · Texto actualizado el 09/10/2026

Ver la colección Mostrar todos: 60700 modelos →
Colección

Por dónde empezar

Todos los modelos de esta colección

Mostrar todos: 60700 modelos
Sobre la categoría

«Furniture Drilling Jig STL Models for 3D Printing»

The results include drilling conductors for 16 mm chipboard and confirmat screws, jigs for mounting hinges and concealed slides, templates for handle holes, and guides for pocket-hole joints. Some are single-piece templates for marking, while others are multi-part jigs meant to clamp onto a board during drilling. Designs also differ in the drill diameters they accept, so a model made for a 5 mm bit may not suit larger hardware.

Before downloading, open the model page and check the overall dimensions and whether the author lists a specific scale. Look at how many parts you need to print and whether the jig requires assembly with screws or magnets. Review the recommended material and layer settings, and look for photos of real prints to judge fit and hole alignment.

If you need a different function, try synonyms such as furniture template, drilling jig, or pocket hole guide. Related topics include cabinet hardware helpers, doweling jigs, and shelf-pin drilling guides. Adding a material thickness or drill size to your query can narrow the results to designs matching your project.

FAQ

Preguntas frecuentes

What is a furniture conductor used for?
It is a template or jig that helps you drill holes in the correct positions when assembling cabinets, shelves, or other furniture from chipboard and hardware.
Can these jigs be printed in PLA?
Many authors list PLA or PETG as workable materials, but you should check the model page for the recommended filament and infill, since drilling forces can stress thin walls.
How do I know if a jig fits my board thickness?
Check the dimensions and description on the author's page; some designs are sized specifically for 16 mm chipboard, while others may be adjustable or intended for different thicknesses.
Do these models need supports during printing?
It depends on the geometry. Look at the author's photos and notes to see whether the model has overhangs that require supports or if it can be printed in a favorable orientation.
