The models differ mainly in what they carry and how they attach. Some are simple brackets that grip a multi-channel relay board, others are full cases that enclose a PCB, and a third group covers single smart relay modules or small boards with a microcontroller and a relay. There are also panels and test stands where several parts sit together, and vertical or dual adapters for tight cabinets.

When choosing a file, look at the rail profile it is drawn for, the footprint of your board, and where the screw holes sit. Check the orientation of the terminals, the space left for wires, and the wall thickness around the clip, since a thin clip flexes differently from a solid block. Read the material and settings the author lists, and look at photos of real prints to judge overhangs and how the part snaps on.

To widen the search, try other words for the same idea: rail bracket, carrier, holder, adapter, Hutschiene, or the number of channels you need. Related topics include PLC housings, terminal block mounts, junction boxes, sensor brackets and cabinet organizers, which often share the same rail geometry and can be mixed in one build.
