Bolt Gauge 3D Models and STL Measuring Tools

This collection gathers 3D models for bolt gauges, thread pitch cards, and nut sorters. You can use them to identify fasteners before ordering replacements or designing a part. Many files are made for quick 3D printing and include both metric and SAE references. Polyzon does not confirm whether models are free, their price, license, official status, affiliation, safety or fitness. Check the current terms at the source.

Il testo di questa raccolta è in inglese; la ricerca funziona in qualsiasi lingua.

Una raccolta di Polyzon · 48 modelli da 4 siti

Come è composta questa raccolta

Polyzon compone questa raccolta a partire dai risultati di ricerca dei siti collegati. I doppioni e i modelli senza anteprima vengono rimossi, le corrispondenze deboli finiscono in fondo e il resto mantiene l’ordine dei risultati. I modelli appartengono ai rispettivi autori: verifica le condizioni sulla pagina di ciascun modello.

Criteri di selezione a cura della redazione di Polyzon · Testo aggiornato: 15/10/2026

Vedi la raccolta Mostra tutti: 2850 modelli →
Raccolta

Da dove iniziare

Tutti i modelli di questa raccolta

Mostra tutti: 2850 modelli
Informazioni sulla categoria

«Bolt Gauge 3D Models and STL Measuring Tools»

Bolt gauges appear as flat cards, plates, and small sorting trays. Some focus on nut sizes, while others include thread pitch checks or a ruler along one edge. Combined tools pack several checks into one print, but they can need more careful orientation.

On the author's model page, check the listed size range, number of parts, and whether supports are required. Look at the layer height, material, and tolerance notes, since thread gauges depend on accurate dimensions. Photos of real prints help you judge how the openings and labels turn out.

If you need a specific standard, search for metric bolt gauge, SAE nut gauge, thread pitch card, or screw sorter. Related terms include fastener organizer, bolt size checker, and measuring card. You can also combine a size term with a format, such as card, plate, or keychain.

FAQ

Domande frequenti

What is a bolt gauge used for?
It helps you match a bolt or nut to a known size or thread pitch. You place the fastener against the openings or thread profiles and compare the fit.
Should I print a bolt gauge in metric or SAE?
That depends on the fasteners you handle most often. Some models include both scales on one card, while others focus on one system.
What material works for a bolt gauge?
A rigid filament such as PLA or PETG is common for flat gauges. Check the author's notes for the material and settings they used.
How can I make the thread pitch check easier to read?
Use a contrasting color for the labels if your printer supports multi-color printing. Otherwise, print at a fine layer height and keep the surface clean.
