The models fall into a few practical groups. Cases and boxes are shaped around a caliper body and often include a slot for the jaws or a compartment for a spare battery. Holders and pegboard mounts fix the tool to a wall, a panel or a bench edge. Radius and angle gauges are separate measuring aids that read a curve or a corner directly, and rulers or scale plates reproduce a graduated edge.

When choosing a model, look at the dimensions the author lists and compare them with your own tool, since caliper bodies differ in length and thickness. Check how many parts are involved, whether they are meant to be glued or screwed together, and whether the author notes supports or a particular orientation. Material and settings matter too: a holder that flexes is usually printed in a different filament than a rigid case, and photos of real prints show how the fit turned out.

To widen the search, try related terms such as vernier caliper, digital caliper, dial caliper, radius gauge, angle finder, goniometer, measuring ruler and pegboard holder. Adding a use case — workshop, electronics bench, drawer insert — or a size range narrows the results further. If you need a part for a specific tool, searching by the tool's shape or the part you want to replace often works better than a general query.
