Longer B1 30 Watt Laser Engraver Z-Axis Adjuster(NO Hardware

Design Concept This Z-axis adjuster for the Longer B1 30W laser engraver is tailored to enable precise control over the engraving height. It's designed without the need for additional hardware, relying on the model's perfect dimensions. ## Purpose The main purpose of this model is to provide an easy and efficient way to adjust the Z-axis level of the Longer B1 laser engraver, ensuring high-quality and detailed laser engravings. ## Printing Tips To achieve high accuracy, print at 0.1mm layer height with 20% infill using durable material like PETG or ABS. Ensure good bed adhesion to maintain the vertical alignment during printing. ## Assembly Instructions The components are designed to interlock perfectly. Simply fit the parts together following the engraver's manual guidelines. .

No tools or additional hardware are required for assembly. Take the laser off the frame. Remove original adjuster screws top and bottom. Place the body between the laser and frame. Sllide the laser back onto the fram. insert the original adjuster screws top and bottom. insert the printed srew into the top. turn left to go up ands right to g down
