O4 Pro Camera Cage for AOS 5 & 5.5 EVO V1.2 Frames

This custom-designed camera cage provides secure mounting for the DJI O4 Pro Air Unit camera module on AOS 5 and 5.5 EVO v1.2 FPV drone frames. The cage offers enhanced protection while maintaining the sleek profile necessary for high-performance FPV flying.

Key Features:

- Perfect Fit : Designed specifically for the DJI O4 Pro camera module (25.55×20×23.30 mm) - Frame Compatibility : Works with both AOS 5 and 5.5 EVO v1.2 frames with their 20x20mm camera mounting patterns 3 4 - Enhanced Protection : Reinforced sidewalls protect the camera during crashes while maintaining minimal weight - Adjustable Angle : Allows for precise camera angle adjustment for optimal FPV experience - Vibration Damping : TPU to reduce jello effects in footage Technical Specifications:

- Compatible with DJI O4 Pro Air Unit camera (32g total weight) - Mount the camera using m2x6 screws (x4) - Fits standard 20x20mm mounting patterns - Supports camera tilt adjustments from 0-40 degrees - Print-in-place design requires no additional hardware - Material: 95a TPU for durability Why This Design: The AOS 5/5.5 EVO v1.2 frames are renowned for their exceptional vibration performance and compatibility with digital FPV systems 7 4 . However, the DJI O4 Pro's upgraded camera module requires a custom mounting solution that wasn't available with the original O3-focused design. This cage bridges that gap while maintaining the frame's performance characteristics.
