5-in-1-out Tile with a 10mm gradient

This is a version that supports a 10mm gradient. 5mm gradient version is here : https://www.printables.com/model/1045537-versatile-5mm-gradient-tile-for-gravitrax

----

When building Gravitrax courses using only genuine parts, I've always been frustrated by the lack of tiles that allow for a 5mm or 10mm drop while also curving at 60 or 120 degrees.

Various designers have created models to address this, and I've printed and used many of them. However, I still face some challenges:

- To accommodate the numerous combinations of drop height (5mm or 10mm) and turn angle (60, 120, or 180 degrees), I need to print multiple models for each variation. This results in a significant number of prints. - There are very few models that allow multiple "5mm or 10mm drop, 60 or 120 degree turn" paths to merge into one. To address these issues, I've designed a new tile. After many iterations and failures, I've finally arrived at this 5 in 1 out tile. It can accommodate turns of 60, 120, or 180 degrees with a single tile and can also be used to merge multiple paths.

----

As you'll find when you try to design, smoothly joining 60-degree short curves is incredibly challenging. This has forced me to rework many of my concepts and designs.

Additionally, tiles with a slope naturally require a sloping design for the entire tile, but I wanted to maximize the usable surface area of the tile by using my custom "Spider Spacers". https://www.printables.com/model/1033087-spider-spacers-for-gravitrax As a result, the top surface of the tile is flat. I apologize for the somewhat crude appearance.

-----

I'm not entirely satisfied with the design, but I think it will serve its purpose!
