SV06 Plus monoblock carriage

A 1:1 replacement for the stock SV06 Plus carriage, printed in one piece!

With all the screw holes at the back retained for mod compatibility

This whole design sits within the stock footprint of the stock carriage, no more compatibility issues!

🤩 Do you like the design? You can help fund innovations like this! Consider supporting me! Much appreciation given to my supporters, and you get exclusive access to various CAD files! Submit feature requests here!

Features: - Supports 4 LM10UU bearings or LM10LUU bearings - Prints with minimal supports - Belt lock - Retains most mod compatibility

Recommended print settings: - Nozzle diameter: 0.4mm - Wall count: 4 - Line width: 0.45mm - Tolerance requirement: 0.2mm - Print orientation: as imported - Supports: not required

Recommended materials: - PETG - ABS/ASA

Installation requires: - 9 * M3 heatset inserts (3 mandatory, 6 optional) - 5 * M3 x 8mm BHCS - 2 * M3 x 4mm BHCS - 5 * M3 nut

Changelog:

Official release Changes

v10

26th Nov 2024

First official release

v14

26th Nov 2024

Added slots for those pesky glue-on mods
