Pool vacuum - easy to print

This is my go at a pool vacuum:

Normal Gardena style garden hose connects to front: water is directed down, redirected flat over the ground and blows all dirt to the other hole at the back end.

This hole is covered with a light sock, hold by a piece of wire. Dirt of collected in the sock and can be emptied easily.

The vacuum itself is connected to a wooden stickb which is held in place by a long screw M5.

O-Ring can be added for garden hose connector.

I also glued some "Moosgummi" rubber like material to the bottom to make sure the pool is not punctured.

... In the end: this is itteraion 2 and it works surprisingly well :-)

150 Minutes print with three shells and 26% infill.

Designed to print without support with only slight bridging challenge for internal water path.

Worked fine on my heavily modified Anet A8.

Have fun printing and using your copy!

Print Settings

Printer Brand:

Anet

Printer: A8

Rafts:

No

Supports: No

Resolution:

0.24

Infill: 26

Filament:

Das filament PETG Red

Category: Sport & Outdoors
