Framework 13 Laptop Display to Portable Monitor Conversion

W.I.P. If you upgraded your display and have an extra sitting around, this model is for you

This model consists of 4 sections.

- The front screen bezel - meant to be 3d printed - screen screws into this part - mostly finished, would be improved if heat set inserts were added. - The back plate - meant to add stiffness and protect the screen for being damaged by bending - there is a stl file for a 3d printed version and a dxf for a laser cut version (sendcutsend will cut and countersink holes for you for less than 40 USD) - stable design, unlikely to be changed much - PCB Housing - you probably sourced a different 40 pin to type-c/hdmi adapter than i used, this part is meant to be modified to fit your pcb. - Meant to be 3d printed only. - Kickstand - I'll be honest, this isn't a good kickstand design and it needs to be updated to something more stable. I'll be designing a nice print in place hinge that locks into position to replace the current design.

This design is definitely a work in progress but if you get the back plate laser cut the updates should maintain compatibility with the original back plate. However the printed backplate is 3mm thick and i printed it with 15% infill in PLA and it works perfectly fine even though the lack of extra weight makes it feel cheaper.

I used flat head M3x8 for everything except the kickstand which uses m3x30 socket head with a nut, but again the kickstand will be updated.

This is the display adapter I used: https://www.aliexpress.us/item/3256805297147520.html Nvarcher Mini Edp To Dp Board 4K Type-C Driver

Be sure to buy it with the cable, the framework laptop display cable will NOT work and may even damage the display or adapter board.
