Ergo Bit Tool - Rotating end & super grip!

Intro

This is an ergoniomic bit tool with a nice textured handle and rotating end piece ! Try it, you will really enjoy working with it!

Why you'll love it?

- Suitable for all HEX bits

- Very small but still a super grip for all your work

- Rotating end piece

- Quick print

Recommended print settings

- Nozzle: 0.4

- Layers: 0.2

- Infill: 100%

- Perimeters: 2

- External perimeters first (important for accuracy)

- Print the main item with facing the bit opening towards the print bed, print the end piece with facing the end to the print bed

- Material: I recommend to use PLA or PETG (see below)

Please mind, every filament has a slightly different behavior and every bit varies slightly in size too. So if it doesn’t work in the first run with your filament/bit, please make sure to activate the “External perimeters first” option in your print settings. You also can try to change the size of the print a little bit (e.g. scale it to 101% or even 102%).

PS: Push both parts together. It will be rather hard, but this is to make it really fit. After this, turn it a few times and it will work smooth. Also: The tool was designed to hold the bit rather tight - it will get worn out when you use it a couple times. Use pliers or a thin nail (opening on the top) to get the bit out.

Filament recommendation

I printed this model using Prusa Prusament and got great results. See below for my recommendations.

Prusament PLA Prusa Orange

Prusament PLA Jet Black
