Nozzle Cleaner for Ender 3 V3 SE (Klipper macro + instruction)

This is an improved version of the Nozzle Cleaner for the Ender 3 V3 SE (A1/A1 mini combs) , optimized for easier use and compatibility with Klipper firmware. This cleaner works efficiently with silicone combs to maintain a clean nozzle during prints.

🧽This macro is designed to clean the nozzle using a silicone comb . It uses a center-based approach , followed by a zigzag motion to ensure thorough cleaning.

🖨 Print settings: 🔷Material: PETG

🔷Layer height: 0.2 mm

🚀! No supports required

🤖 Install the Macro:

✅Copy the WIPE macro into your marco.cfg file on Klipper.

[gcode_macro WIPE] description: Wipe nozzle on silicone comb (center-based + zigzag)

# Comb parameters variable_comb_x: 138.0 ; X center of the comb variable_comb_y: -12.3 ; Y center of the comb variable_comb_z: 3.18 ; Z when touching the comb

# General parameters variable_comb_z_lift: 5.0 ; Nozzle lift before/after wiping variable_comb_width: 40.0 ; Full width of the comb (mm) variable_comb_cycles_1: 4 ; Number of cycles in the first pass variable_comb_cycles_2: 3 ; Number of zigzags in the second pass variable_comb_offset_y: 1.0 ; Y offset for the second pass variable_comb_zigzag_shift: 1.5 ; X shift for each zigzag step

# Return to specified position variable_return_x: 100.0 variable_return_y: 20.0

gcode: {% set half_width = comb_width / 2 %} {% set zigzag_shift = comb_zigzag_shift %}

G90 ; Absolute coordinates G1 Z{comb_z_lift} F3000 ; Lift nozzle before moving G1 X{comb_x} Y{comb_y} F6000 ; Center of the comb G1 Z{comb_z} F3000 ; Contact with the comb

; First straight pass G91 ; Relative coordinates {% for i in range(comb_cycles_1) %} G1 X{half_width} F4500 G1 X-{half_width * 2} F4500 G1 X{half_width} F4500 {% endfor %}

; Lift slightly and move Y offset G1 Z0.3 Y{comb_offset_y} F3000

; Second pass — zigzag along X with a slight shift {% for i in range(comb_cycles_2) %} G1 X{half_width + (zigzag_shift * i)} F4500 G1 X-{(half_width + (zigzag_shift * i)) * 2} F4500 G1 X{half_width + (zigzag_shift * i)} F4500 {% endfor %}

; Lift and return G90 G1 Z{comb_z_lift} F3000 G1 X{return_x} Y{return_y} F6000 G4 P500

📝Adjust the parameters, such as the comb's center ( comb_x , comb_y ) and width, based on your specific setup.

✅Go to center comb

✅look at the coordinates in the klipper

✅ write them into a macro

✅add WIPE in your PRINT_START

🎉 Congratulations

☕ If you like it, you can support me with a cup of ☕ at ko-fi.com/dm1trym

Disclaimer : This nozzle cleaner and associated macros are provided as-is. The user assumes full responsibility for any damage or issues that may arise from using this design or code with their 3D printer. Always ensure proper calibration and testing before using with your machine.
