Gridfinity Pinecil / TS100 Soldering Iron Stand

a gridfinity magnet base for the pinecil and ts100 soldering iron, has a compartment for brass sponge to replace the giant spring soldering iron holders. designed so the tip does not extend past the back side of the base so it can still be stacked in with other gridfinity bins (if youre careful).

this holder uses;

- 2x - 608 size bearings - 1x - M3x12 screw - 1x - M3 hex nut - (optionally) 6x2mm magnets for base the bearing holder section is printed in a separate part to allow for the best print orientation and angle for the iron to sit, gluing it into the slot is unnecessary but not a bad idea.

i recommend printing the bearing holder part in 100% infill, and out of ASA or PETG so it can better resist the heat of a long soldering session.
