Banded Killifish Swimbait (Fishing Lure)

This model is similar to my shiner swimbait but it is based on a different fish and it has 3 segments. I designed this model only using Fusion 360. I like printing all my lures in 0.1mm because they don't take too long to print and it gives better looks. Once you put the front, middle and back into Prusaslicer it should already be oriented like it would be in the water except the fins (fins print separately). Use the cut feature and make sure you select parts (DO NOT SELECT OBJECTS). The cut plane should already at about the halfway point or a little bit lower. If not move the cut plane to halfway. Then go into the sidebar on the right and change the bottom parts of each of the objects infill to 100%. You'll need to print fins separately in TPU for the most durability. You may need to cut out a little circle for your hook hanger on the bottom fin. Refer to my Popper 3D model if you need any help with the cutting into parts and the infill.

Popper Fishing Lure by Brownie86 | Download free STL model | Printables.com

Settings:

Infill-25% (Modify bottom as mentioned before, only change masters)

Layers-3 Perimeters

Quality-0.1mm

Supports-Yes, custom or auto generated

Filament-Print in PLA or PETG for the most strength (I like overture 3d filaments)

Let me know if you have any questions or concerns,

As always thank for considering printing.
