30mmx5 rod

Customized version of http://www.thingiverse.com/thing:193647

Created with Customizer! http://www.thingiverse.com/apps/customizer/run?thing_id=193647

Instructions

Using the following options:

thread_step = 1.5

resolution = 0.5

inner_diameter = 8

texture = exclude

slot_depth = 2

type = rod

slot_width = 1

drive_diameter = 5

countersink = 2

outer_diameter = 14

thread_length = 30

non_thread_diameter = 0

thread_outer_diameter = 5

drive_type = socket

nut_thread_outer_diameter = 9

wing_ratio = 1

nut_type = normal

non_thread_length = 0

head_diameter = 12

step_shape_degrees = 45

nut_resolution = 0.5

nut_thread_step = 2

nut_height = 6

head_type = hex

facets = 6

thickness = 2

nut_diameter = 12

head_height = 5

nut_step_shape_degrees = 45

Category: Parts
