92mm fan holder with extra low profile (Noctua NF-A9x14)

This fan holder is originally for a Noctua NF-A9x14 , but other 90x14mm fans might fit aswell.

I designed this 92x14mm fan holder to as flat as possible. It is based on the 60mm version is designed.

You can mount this holder in different ways:

- Use two Ø12x6mm magnets to hold in the base. - Use threaded inserts, the wholes are designed for inserts with Ø5mm outer diameter, but other might fit as well. - With screws through the holes from the top. Other magnets: If you want it to fit other Magnets let me know, I might have time to make another version for you.

CAUTION: I did not print this. It is designed based on the fan dimension. Please check physical dimensions before printing.

This design is part of my frame, bracket and holder collection for various boards and components: https://www.printables.com/@a123qwertz567/collections/2632544

Check the 60mm version here: https://www.printables.com/model/395099-60mm-fan-holder-with-extra-low-profile-noctua-nf-a

Print instructions:

- recommended layer height 0,2 mm - No supports needed

I would be happy to see some of your makes posted :)

Source files in the Alibre Atom format is available but the website does not allow the upload. If you need it send me a message.
