Prusa I3 MK3S MMU2S with Bondtech BMG MK3 adaptation

This is a compilation of things in order to upgrade (or build) your Prusa I3 MK3S with MMU2S and Bondtech BMG extruder kit for MK3.

I used the Bear X-Carriage with an adaptation for the Bondtech extruder and MK3S filament sensor (source: https://www.thingiverse.com/thing:3560116 ).

Also put here a cover for the laser sensor compartment of the Bondtech BMG extruder as the filament sensor is mounted on the door on the MK3S MMU2S adaptation (source: https://www.myminifactory.com/object/3d-print-prusa-laser-sensor-delete-93976 )

The filament sensor is mounted on the extruder gear door (source: https://www.thingiverse.com/thing:3565326 ), but I remixed the 10mm top plate cover in order to remove two chamfer on two sides, now it looks better.

Print instructions

Category: 3D Printer Extruders Print Settings

Printer Brand: Prusa

Printer: I3 MK3S

Rafts: No

Supports: Yes

Resolution: 0.2mm

Infill: 40%

Filament: Generic ABS and PETG Black
