Sovol Zero / SV08 (MAX) Toolhead second part cooling fan duct

This is a printable version of the part cooling fan duct for the Sovol Sv08 Max and Zero Toolhead print the modell laying on its side by the bracing and insert 2x M2 heat set inserts with the stock screws.

I used this model to upgrade my SV08 with the Zero toolhead and used the stock SV08 toolheads fan and screws.

You need to plug the second fan into the top port in the middle and configure it in your printer config i did it like this:

[fan_generic fan0] # back model cooling fan

pin: extruder_mcu:PA7

max_power: 1.0
