Parametric Gridfinity Bin Generator (Fusion 360)

Parametric Gridfinity Bin Generator (Fusion 360)

A fully parametric Fusion 360 model for generating custom Gridfinity bins — with enhancements not typically included in standard bin files.

Create bins tailored exactly to your storage needs — from small fastener trays to large multi-compartment organisers — without relying on pre-made STL variants.

Enhancements

- Optional compartment splitting (any divider count)

- Optional label platform with debossed text

- Optional front scoop for easier part access

- Optional magnet pockets with adjustable diameter and depth

- Optional M3 screw holes for additional base mounting options

- Optional rabbit/mouse ear brims for larger bins

- Anti-warp perimeter tension-relief ring

- Designed to remain stable when parameters change — no timeline errors

What Is Gridfinity?

Gridfinity is a modular storage system created by Zack Freedman, based on:

- 42 × 42 mm footprint per unit

- 7 mm height increments

- Stackable geometry

- Optional magnet retention

These bins are fully compatible with standard Gridfinity bases.

Core Parameters

Parameter

Description

UnitsWidth

Width in Gridfinity units (42 mm each).

UnitsLength

Length in Gridfinity units (42 mm each).

UnitsHeight

Height in Gridfinity units (7 mm increments including base).

CompartmentCount

Number of compartments. Divider walls are generated automatically.

EnableLabelPlatform

Toggles the label platform.

LabelText

Optional debossed label text. Use empty quotes ( '' ) to remove text.

EnableMagnetPockets

Toggles magnet pockets in the base.

MagnetDiameter

Diameter of magnet pockets including printer tolerance (2–9.5 mm).

MagnetHeight

Depth of magnet pockets including printer tolerance (up to 4.75 mm).
