NAVEE N65i II – U-Lock Mount (40 mm Tube)

This 3D-printed mount is designed to securely attach a U-lock holder to the steering tube of the NAVEE N65i II electric scooter .

The clamp fits a 40 mm diameter tube , which matches the stem size of the scooter. The mount consists of two clamping parts that are tightened together using M4 hardware to create a strong and secure hold.

The design includes reinforced side brackets to attach a standard U-lock holder plate .

The holder is designed for U-lock bars with a diameter of approximately 16.6 mm .

Features

- Designed specifically for NAVEE N65i II

- Fits 40 mm tube diameter

- Strong clamping design for stable mounting

- Compatible with many common U-lock holder plates

- Lightweight but rigid structure

- Easy to print without supports (depending on slicer settings)

Hardware Required

For assembly you will need:

- 6 × M4 x 10 mm screws

- 6 × M4 nuts

The screws clamp the two halves together and secure the mounting plates.

Assembly

- Place the two clamp halves around the scooter stem.

- Insert the M4 x 10 screws through the holes.

- Secure them with M4 nuts .

- Tighten evenly until the mount sits firmly on the tube.

⚠ Do not overtighten to avoid damaging the printed part.

Notes

- Designed for 40 mm tube diameter .

- If your printer tolerances are different, you may need slight scaling or sanding.

- Printing in PETG or ABS is recommended for better durability. But PLA is also okay to use.
