Mac Mini M4 VESA monitor holder

This is a versatile, modular mounting solution for the Mac mini M4, designed to attach directly to the side of your monitor's VESA mount.

The system features a modular interface, meaning you can easily swap or create your own custom add-ons to fit your specific desk setup.

🛠 Bill of Materials (Hardware)

Component

Purpose

Quantity

M3 x 8mm Screws

To attach add-on piece & lock-piece

3

M3 x 4mm Heat-Set Inserts

Threading for add-on / lock-piece

4

M4 / VESA Screws

To attach the holder to your monitor

2*

*Note: The length of the VESA screws depends on your specific monitor or mount.

💡 How to Mount

- Prepare the Mount: Install the 4x M3x4mm heat-set inserts into their corresponding slots.

- Attach Add-on (Optional): If using the DISKS module, align it with the main body and secure it using 2x M3x8mm screws (it features 4 total holes in case you want to design and create your own personalized add-ons).

- Secure the Mac mini: Use the 1x M3x8mm screw with the small Lock-piece to lock the Mac mini securely in place.

- VESA Installation:

- You do not need to fully remove your monitor from its mount or stand; it can safely remain hanging while you install the holder.

- Simply remove two screws from one side (either top and bottom on the right or left) of your monitor's VESA mount.

- Align the holder with those VESA holes and secure it using your monitor's VESA screws (length depends on your setup).

Modular Design & Custom Add-ons

This holder is built with a modular concept in mind. While it comes with the DISKS add-on module, the mounting interface is designed so that you can create your own custom add-ons!
