Citrus Juicer with handle

Thks Walter for the design!

I just wanted to have a handle to easily apply more fore pushing the juicer into the fruit and twisting it.

Benefit is, you do not have to use a brim or raft for printing any longer…;)

Since the original size has a 60mm diameter, it tends to be a little gib for regular lemons (the ones at my shop normally come with around 50mm diameter).

So just use the scaling functionality of your slicer to adopt according to the fruit size you want to juice.

v1_2 now has a "healed" STL, so there should be no issues with slicing.

Print Settings

Printer:

SecKit SK-Go²

Rafts: No

Supports:

No

Resolution: 0.25

Infill:

50

Filament:

Sunlu PETG White

Notes:

...but PLA and ABS should also do..

How I Designed This =================== FreeCAD

model included.

I just marked the imported STL and the designed handle and exported both into one STL. Therefore I not had to transfer the imported STL into a solid.

Category: Kitchen & Dining
