Grok Logo - 240 mm Flat Decoration

A flat Grok logomark for indoor decoration. The two original arcs remain separate pieces, without a connecting bridge or backing plate.

Size and printing

- The supplied print footprint is 129.632 x 240 mm; thickness is 6 mm.

- Print flat as exported, without supports, using a 0.4 mm nozzle assumption.

- The outline is rotated 45 degrees to place its tips along the bed Y axis. Rotate the finished decoration by -45 degrees for the upright logo orientation.

- The common STL preserves the relative positions of the arcs. Keep them together when importing; do not automatically arrange the arcs independently if you want to retain that spacing.

- Individual arc STLs are included as alternatives. They use the same coordinates as the common STL.

- Center on the P1P's 256 x 256 mm plate and check plate edges, the front-left exclusion zone and all added plate objects before printing.

The pieces have no mounting holes or interlocking connection. Material, mounting method and physical printing have not been tested.

Editable source

Keep the SCAD and SVG together. Change footprint_height or thickness to resize the model. The source validates a 45-degree print rotation and at least 8 mm bed margin.

openscad -D 'part="logo"' -o grok_logo_240mm.stl grok_logo_240mm.scad openscad -D 'part="upper_arc"' -o grok_logo_240mm_upper_arc.stl grok_logo_240mm.scad openscad -D 'part="lower_arc"' -o grok_logo_240mm_lower_arc.stl grok_logo_240mm.scad

Use either the common STL or the two individual STLs, not both sets on the same plate.

Verification

Geometrically checked and successfully sliced on 2026-10-11 in Bambu Studio 2.8.2.61 using the P1P 0.4 mm profile, 0.20mm Standard, PLA Basic and Textured PEI Plate. The centered footprint occupies approximately X=63.18-192.82 and Y=8-248 mm on the plate, clear of the front-left exclusion zone. No supports or brim. Estimated time and material: 39 min and 24 g. These are slicer estimates; no physical test print is claimed.

Artwork

The local contour is from the official Grok logomark on x.ai, retrieved on 2026-10-11. This is an unofficial decorative 3D adaptation.
