Star Wars Sith Empire LED Logo

This is a Sith Empire LED Logo.

The Front Shell was printed with Black PLA at 20% infill.

The Logo Diffusion was printed with Transparent PLA at 100% infill. You will need to sand the logo diffusion pieces down just a smidge to make sure you can squeeze it into the allocated spots. This was the only way I could figure to try to eliminate any gaps of light and get as a tight a fit as I could. I used Wirecutters (not to actually cut) but to press the different transparent pieces into the Front black shell (you just need something strong and small to force the pieces in together).

I then used this LED strip I got on amazon: https://www.amazon.com/gp/product/B07RY76LGX to do 3 layers of leds on the inside (see the pictures).

The Back Mount you can print with any color (I used transparent) as it's hidden. The Back Mount is actually 2 pieces. The smaller inner hexagon you mount on the wall using the holes. (I used screws and drywall anchors).

The other piece of the Back Mount you do the same method of fitting it into the back of the Front Shell as you did with the diffusion pieces. After that its just a matter of lining up the hexagons and pressing it onto the smaller inner hexagon you mounted on the wall.

Print Settings

Printer Brand:

Creality

Printer: Ender 3 Pro

Rafts:

Yes

Supports: No

Resolution:

200

Infill: 20

Filament: Ender Series PLA

Notes:

See the summary above for more printing details.

Category: Decor
