Steel Sheet Holder for Prusa i3 (Under-Table Mount, Fits MK4, MK3, MK2)

Keep your Prusa i3 steel sheets organized and dust-free with this sturdy, under-table storage solution. Designed for all recent Prusa i3 models with a standard bed size, this holder will not fit the Prusa Mini due to its smaller bed dimensions. For a Prusa Mini-compatible version, check out the remix link at the bottom of this description (credit to D1ngsbums ! ).

This holder set includes two parts – a left and right holder – designed to mount under tables or desks, not vertically. It fits up to 7 sheets (possibly more, depending on part thickness), offering a compact, space-saving storage solution without the need for spacers. These models are also stackable to allow for more sheets!

Version Updates

- Version 2 : Improved usability with the same mounting holes and outer dimensions as Version 1. - Version 1 : Be sure to scale to 1000% when slicing, as it was initially drawn in mm. V2 corrects this. Installation Tips

For mounting, consider these methods:

- Easy Option : Use command strips or mounting tape . This method is quick and avoids the need to flip your table. Position the holders upside down, press firmly, and let the tape hold the parts in place. - Best Option : To mount with screws, start by securing with mounting tape to position the holders and steel sheet exactly as desired. Then, use four 5x20mm wood screws to secure each piece. This ensures perfect alignment without needing extra hands or flipping the table. Parts Needed

- 1 Left Holder (Version 2) - 1 Right Holder (Version 2) - 4 wood screws (5x20mm) OR 4 command strips/mounting tape (Any size command strips work; the smallest size holds well under an Ikea Lack table and can later be secured with screws if desired.) Printing Notes

Category: 3D Printer Accessories Print Settings

- Printer Brand : Prusa - Printer Model : I3 MK3S - Rafts/Supports : No - Orientation : Rotate parts sideways to fit the bed. May need to remove skirts or brims to fit on the bed.

Check out the Prusa Mini bed remix here:

https://www.prusaprinters.org/prints/71096-prusa-mini-steel-sheet-holder-for-under-tables-she
