Meanwell LRS PSU 2020 extrusion mount

Mount for a Meanwell LRS power supply to 2020 extrusion. Designed to mount to a corner but could be attached elsewhere using fewer bolts & T-nuts.

Model uses M4x5mm bolts throughout, 4 to attach PSU to housing, 4 to attach housing to plate, 4 to attach plate to extrusion. Where the plate attaches to the extrusion, M4 T-nuts are required.

Hardware required

12 x M4x5mm

4 x M4 T-nuts

Assembly

You must screw the housing to the plate first, then install the power supply. Use M4 bolts to screw the housing to the PSU. Position the terminal cover on the housing, then use filament as the hinge pins.

Support is optional - depending on your printer / part cooling. The terminal cover has 45 degree arms if printed on it's front face.

Step file attached, created in OnShape (linked).
