Titan Aero mgn12 carriage (CR-10, BLV mgn AM8) w/ BL Touch/ABL

I crudely stitched the original BL Touch mount back onto the carriage. This is the Volcano* and * V6 version, pick which one you need. It is not tested and I have no way of testing as I do not have a BL Touch or ABL. I have a feeling the mount arm may be a tad too short. I did not change the BLT/ABL mount in any way.

* !!!Feedback welcome/necessary!!! *

You will still need to download the appropriate fan duct and BLT/ABL mount from thing:3078853 . And you may want to print my adapter if you plan on mounting this to a BLV mgn12 AM8 mod.

Since the volcano version of the carriage sits higher up, the volcano version of the BL Touch mount may be too low. Not sure.

I'll get a BL Touch eventually... maybe. I have a BLTouch on my delta but I have absolutely no intention of getting any ABL system on my AM8. Therefore, I will never be able to test this part.

Update (9/23/2019): Added a non-ABL version of the v6 mount for countersunk screws... I need them for my personal setup. I could only find M5 screws as countersink Phillips head screws locally. They don't grip well with the stock setup and have a small amount of play no matter how tight I get 'em.

How I Designed This

I used Meshmixer to plane cut the mount off the original carriage. I then used Windows 3D builder to stitch that mount onto the remixed mgn mount.
