Voron 2.4 300x300 extrusion cover

This is a extrusion cover for Voron 2.4 300x300.

It covers the 2020 extrusions and add dampening to the bottom deck with foam.

Same model printed 2 times since left and right is the same, no supports needed.

Printed with 0.2 layer, 5top/bottom, 4 walls and 40% grid infill.

BOM

M3 shcs 6mm x8

M3 shcs 10mm x14

Rollin T-nut M3 x22 or Hammerhead T-nut M3 x22

5x2mm foam

https://github.com/VoronDesign/VoronUsers/tree/master/printer_mods/wile-e1/Deck_Panel_Support_Clips ( wile.e-deck_panel_support_lower_adjustable(3-6mm).stl) as many as u want in the electronics bay to support the deck panel, i used 12.
