Prusa i3 MK3S Noctua Extruder fan cover

Сведения о модели

Площадка
Printables
Цена
Бесплатно
Лицензия
CC0
Общественное достояние: можно печатать, изменять и продавать без указания автора.
Форматы
STL
  • 78 Лайки
  • 672 Загрузки
  • 12 Напечатали
  • 29 Комментарии
  • 4 990 Просмотры

Автор:Petclaud

Опубликована

Описание

The first Prusa MK3's were shipped with Noctua fans with hideous colors. Hence I made a cover for the Noctua fan as found here: https://www.thingiverse.com/thing:2730049

When Prusa released the new MK3S parts, some modifications to the cover had to be made, to fit the new Prusa parts.

The principle remained the same: The cover has some notches that will "snap" into the rear bolt heads and the front is kept in place by 2 M3 bolts going through the cover - just look at the pictures it should be self explanatory.

The top M3 bolt is 18 mm long, the bottom M3 bolt is 25 mm long - these can be retrieved from the supplied spare bolts.
