Eryone Thinker SE Linear Rails Y axis Mod

Mod for mounting linear rails on the Y axis of the Eryone Thinker SE.

Linear rails are 2x MGN12H 400mm.

There are 2 versions for the Endstop and Belt Adapter, read carefully!

Linear Rail on X axis

Print Belt-Adapter and Endstop-Adapter.

NO Linear Rail on X axis

Print Belt-W-Adjustable-Endstop. It is supposed to work by placing an M5 screw in the big hole to advance and retract the Y endstop. Please note that this part is not tested, as I have the full mod.

Print Settings

Printer:

Eryone Thinker SE

Rafts:

No

Supports:

No

Resolution:

0.28

Infill:

50%+

Filament:

Eryone PETG

Orange/White

Notes:

Print everything in PETG.
